C8 Corvette HTC Experimental 650hp twin turbo package.

C8 Corvette HTC Experimental 650hp twin turbo package.

We have been getting a lot of calls over the last few years to produce a hard top convertible version of our twin turbo set up. We are now offering an experimental version of the kit. This kit was designed to fit the HTC version of the C8 Corvette. The kit comes with everything the hard top version has to offer but a few things will differ. The intake manifold will be reused that GM puts on the car. Instead of using our custom intercooled LT2 intake manifold we will build a custom air to water intercooler system that will take offer the factory are box location in the HTC Corvette. The manifolds pictured are the custom long tube race style that e have used in the past on our v1 and v2 twin turbo set ups. We will also have all of the hot side exhaust and turbo parts covered in HeaderShield. We put some images of what the heat control will look like images are from HeaderShield.

HeaderShield is a bi-layer insulation and encapsulation system for anywhere you want to keep the heat in or out. Consisting of special, inner insulation layer and durable, stainless steel outer shell, HeaderShield™ provides much higher insulation values, durability and mechanical specs than ceramic coating or conventional exhaust wrapping tapes.

HeaderShield™ direct insulation system is designed to withstand long-term temperatures exceeding 1100 degrees Celsius in harsh environments. It is water, oil and vibration resistant and can be applied to wide range of materials – stainless steel, aluminum and other non-ferrous metals or even plastics. Lightweight and easily customizable Headershield™ is environment-friendly and not hazardous during manufacturing, installation, handling and use.

• Reduce surface temperatures by 60% Up to 1100 C
• Protection for heat sensitive and critical engine components
• Improved exhaust gas velocity
• Cooler intake air temperatures
• Reduced radiant heat in engine and passenger compartment
• Ability to insulate bespoke systems or production level quantities

As stated this is an experimental package for the HTC Corvette. We are offering a discount to any customer who would like to lend their car to ECS so we can test everything. This will allow fitting of the system and testing but also give a supporter of the community an amazing twin turbo system at a discounted cost.

Installed pricing starting at $32,995 with HP Tuners calibration.

⊛Trans pressure controller included

⊛ Precision 62/66 or 64/66 Mirror Image Turbos

⊛ Custom Stainless Steel “Hybrid” CNC Turbo Manifolds w/ priority flow to wastegates

⊛ Stainless Steel Downpipes to OEM Catalytic Converters (EPA Compliant)

⊛ Twin 45mm Wastegates

⊛ Custom 1,500HP High Efficiency Air To Water Intercooler System

⊛ Twin 50mm Blow Off Valves

⊛ Factory Fuel System

⊛ Upgraded Valve Springs

⊛ Custom powder coating on intake and cold-side ducting

⊛ Billet Aluminum CNC Chassis Brace Bars

⊛ PCV and Catch Can System

⊛ Factory ECM Tuning w/ HP Tuners
